Construction Bamboo Plywood, also known as bamboo glued board or construction bamboo template, is a high-strength artificial board made from high-quality moso bamboo, processed by slicing, steaming, preservation, drying, forming, and high-temperature, high-pressure phenolic resin pressing. It is divided into four major categories: plain bamboo plywood, film-covered bamboo plywood, bamboo mat-veined plywood, and full-thick bamboo reinforced plywood.
Construction Bamboo Plywood is formed by hot pressing multiple layers of bamboo mats and sheets. The tensile strength and bending resistance of bamboo fibers are far superior to those of wood adhesive boards made from poplar or eucalyptus. When used for casting large-span floor slabs and beams/columns, it is less prone to bending, warping, or mold deformation, which can appropriately reduce the amount of supporting timber and steel pipes, saving auxiliary material costs and lowering the risk of construction mold failure. It is also resistant to cracking and delamination even with repeated nailing and disassembly, making it a commonly used high-strength waterproof formwork material for building concrete casting, heavy-duty packaging, and ship/vehicle bottoms.
Product Parameters
|
Test Item |
Standard Parameter |
|
Moisture Content |
8%～12% |
|
Longitudinal Bending Strength |
≥90MPa |
|
Longitudinal Elastic Modulus |
≥7500MPa |
|
Glue Bond Strenght |
≥1.0MPa(Phenolic TypeⅠwaterproof adhesive) |
|
Air-Dried Density |
0.75～0.95g/cm³ |
|
24h-Hour thickness swelling rate |
≤8% |
|
Reuse times |
10～15 times |
Product Advantage
High strength & excellent load-bearing performance
Using high quality moso bamboo as the raw material, the bamboo fibers have strong toughness. The density of the board is much higher than wooden formwork. Construction Bamboo Plywood has outstanding bending, compression and impact resistance. It is not prone to bending and collapsing during high supporting formwork, large-span floor construction or bridge construction. The support spacing can be appropriately widened, reducing the material consumption of the scaffolding.
Waterproof & moisture-proof, without layering or expansion
Our Construction Bamboo Plywood is made by pressing phenolic waterproof glue. It has a low water absorption and expansion rate. In damp conditions such as basements, during rainy seasons in open areas, or in water reservoirs, it will not bulge, peel, or separate even after being soaked in water for a long time. It has excellent anti-insect and anti-mildew effects.
Smooth & flat surface, easy to remove the formwork
Our Construction Bamboo Plywood does not adhere to the concrete, no need to apply release agent during construction. The beams, columns and walls are smooth and flat after demolding and achieving good appearance of the concrete in its natural state. It significantly reduces the labor costs for later plastering and repair.
Excellent dimensional stability, less prone to deformation or leakage of concrete
Our Construction Bamboo Plywood are formed by interlacing bamboo curtains and bamboo mats, which counteract the one-way stress of the panels. The dry shrinkage and wet expansion range is small, reducing the probability of warping and arching during use. The panel joints have uniform gaps, effectively preventing mortar leakage during pouring.
Product Application
Film Faced Bamboo Plywood Product Application
Residential construction projects
Shear walls, beams and columns, floor slabs of high-rise and small high-rise residential buildings, basement, garage, and civil defense projects, moisture-proof and waterproofing, no swelling or deformation;
Road and water conservancy projects
Overpasses, municipal bridge abutments, piers, curved surface formwork of box girders, tunnels, culverts, river banks, dams, and water conservancy projects for hydropower stations;
Municipal infrastructure
Urban pipe galleries, comprehensive pipe trenches, retaining walls, pedestrian overpasses, concrete pouring for sewage tanks and septic tanks, suitable for humid working conditions;
Special industrial pads
Container bottom plates, cargo vehicle compartment load-bearing pads, temporary pads for construction site roadbeds, load-bearing pads for large equipment.
Company Profile
Shenzhen Linya Building Materials Co., Ltd. has been dedicated to the R&D and production of building formwork and materials for 10 years, with business cooperation spanning over 70 countries worldwide, involving more than 9,000 project engineering projects. Its main products include Steel Prop,Construction Bamboo Plywood, Plastic Formwork, PP hollow building formwork, PVC plastic formwork, Film Faced Plywood, LVL board, H20 Timber Beam and other full categories of building materials.
Own Factory
Own 150,000㎡ intelligent manufacturing plant in Linyi, with fully automated production lines and complete supporting facilities. Sufficient production capacity, strict quality control, stable quality, and customizable according to needs;
Professional Team
Shenzhen professional foreign trade team operates its own export, one-stop service for quotation, documents, logistics, and after-sales, giving you peace of mind.
10 Years
150,000 ㎡
70+ Countries
9000+ Projects
Production Workshop
Product Packaging
Construction Bamboo Plywood Packaging
1. Loose Packing:
Load more quantity and save cost
2. Pallet packing:
Easy to Load and Lade
Container Loading and Shipping
FAQ
Q: What types of construction bamboo plywood can you offer?
A: Plain, film-faced, bamboo mat veneer, full thick bamboo reinforced plywood.
Q: Is it suitable for large-span floor slabs, beams and columns construction?
A: Absolutely. It hardly bends or deforms for large concrete pouring projects.
Q: What's your MOQ?
A: MOQ is flexible; small trial orders and full container loads are both acceptable.
Q: How long is your production lead time?
A: Stock goods ship in 3–5 days; customized bulk orders take 10–25 working days.
Q: What glue do you use for bonding? Is Construction Bamboo Plywood waterproof?
A: Waterproof phenolic resin glue, suitable for outdoor and wet construction sites.
Q: What size and thickness can you supply for construction formwork?
A: Common standard sizes: 1220x2440mm (4x8 feet). Thickness options: 6mm - 20mm. We accept customized length, width and thickness as your construction project needs.
Q: What is your loading and packaging method for sea shipment?
A: Two options: a. Pallet packing--Boards are packed well by standard export wooden pallets, fixed with steel strips to avoid damage during long-distance sea transport; b. Loose bulk loading directly on the container, can load more quantity and save shipping cost. We support full container load (FCL) and less container load (LCL).
